Lenovo ThinkPad P16v G2 Mobile Workstation (21KX002QUS): Unleash Professional Power

  This second generation of the P16v series offers a compelling blend of raw power, a stunning display, and the renowned reliability and features of the ThinkPad line, making it ideal for engineers, designers, content creators, and data scientists on the go. Processor and AI Capabilities: The 21KX002QUS is equipped with the Intel® Core™ Ultra 7 155H Processor. This "Meteor Lake" processor features a hybrid architecture designed for performance and efficiency:

• Cores/Threads: 16 Cores (6 Performance-cores, 8 Efficient-cores, 2 Low Power E-cores) and 22 Threads.
• Max Turbo Frequency: Up to 4.80 GHz (P-cores).
• Intel AI Boost NPU: The integrated Neural Processing Unit (NPU) accelerates AI workloads directly on the device, enhancing performance for AI-driven applications, video effects, and other smart features.

Graphics: For professional graphics workloads, the workstation features a dedicated NVIDIA RTX™ 2000 Ada Generation Laptop GPU with 8GB of GDDR6 VRAM.

• Architecture: Based on NVIDIA's latest Ada Lovelace architecture, it provides significant performance improvements over previous generations for tasks like real-time ray tracing, AI-accelerated rendering, and complex 3D modeling.
• TGP (Total Graphics Power): In the ThinkPad P16v G2, the RTX 2000 Ada typically operates within a TGP range of 60W to 80W (with boost), ensuring robust performance while managing thermal output suitable for a mobile workstation. It is ISV (Independent Software Vendor) certified for optimal performance with professional software.

Display: The 21KX002QUS boasts a high-end 16-inch WQUXGA (3840 x 2400) IPS Anti-Glare Non-Touch display.

• Resolution and Aspect Ratio: The high 4K (WQUXGA) resolution at a 16:10 aspect ratio provides incredible detail and ample screen real estate for intricate work.
• Brightness and Color Accuracy: It offers an impressive 800 nits of brightness, supports HDR 400, and covers 100% DCI-P3 color gamut, making it excellent for color-critical tasks. It also features Low Blue Light technology for eye comfort and X-Rite Factory Color Calibration for out-of-the-box color accuracy.
• Refresh Rate: 60Hz, standard for high-resolution professional displays.

Memory and Storage:

• Memory: This configuration comes with 64GB of DDR5-5600MHz RAM, configured as 2 x 32GB SODIMM modules, allowing for substantial multitasking and handling of large datasets. The P16v G2 supports up to 96GB of DDR5 memory.
• Storage: It includes a 1TB M.2 2280 PCIe Gen4 Performance TLC Opal SSD. The workstation typically features two M.2 PCIe Gen4 NVMe slots, offering expandability for additional storage, and supports RAID 0/1 configurations.

Design and Build Quality: The ThinkPad P16v G2 maintains the classic ThinkPad aesthetic with a durable black chassis.

• Materials: Likely a combination of aluminum and high-quality PC-ABS for robustness.
• Durability: It is MIL-STD-810H tested, ensuring resilience against various environmental conditions and physical stresses.
• Keyboard and Touchpad: Features the renowned ThinkPad backlit keyboard with a full numeric keypad and spill resistance. The dual-function TrackPoint and a large TrackPad (115mm) with three physical buttons provide versatile navigation options.
• Cooling: Designed with an efficient thermal solution to manage the powerful CPU and GPU under sustained loads, crucial for workstation performance.

Connectivity and Other Features:

• Ports: Comprehensive port selection for a workstation:
  • 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps) with DisplayPort™ 2.1 and Power Delivery 3.0
  • 1x USB-A (USB 5Gbps / USB 3.2 Gen 1, Always On)
  • 1x HDMI® 2.1 (supports up to 8K@60Hz or 4K@240Hz)
  • 1x Ethernet (RJ45)
  • 1x SD Express 7.0 Card Reader
  • 1x Headphone/microphone combo jack (3.5mm)
  • Optional: Smartcard reader
• Wireless: Intel® Wi-Fi 6E AX211 (802.11ax 2x2) with vPro® capabilities for robust and secure wireless connectivity, and Bluetooth® 5.3. WWAN Ready (Antenna Only, No Card) means it can be upgraded for mobile broadband.
• Webcam and Audio: Features a 5MP RGB+IR camera with a privacy shutter and Human Presence Detection for enhanced security and video conferencing. Dual far-field microphones and stereo speakers with Dolby Audio™ and Dolby Voice® provide clear audio.
• Security: Integrated Fingerprint Reader, dTPM 2.0 chip, and ThinkShield security features.
• Battery: 90Whr battery with Rapid Charge support (80% in 60 minutes with the 170W adapter).
• Operating System: Ships with Windows 11 Pro 64-bit, optimized for professional environments.

The Lenovo ThinkPad P16v G2 Mobile Workstation (21KX002QUS) is a robust and powerful machine engineered for professionals who require high-performance computing, advanced graphics capabilities, and exceptional display quality for their intensive workflows.

---



Key Specifications:



• Model Name: Lenovo ThinkPad P16v G2 Mobile Workstation
• SKU: 21KX002QUS
• Processor: Intel® Core™ Ultra 7 155H Processor
  • 16 Cores (6P + 8E + 2LPE), 22 Threads
  • Max Turbo Frequency: Up to 4.80 GHz
  • Integrated Intel AI Boost NPU
• Graphics: NVIDIA® RTX™ 2000 Ada Generation Laptop GPU 8GB GDDR6
  • TGP: 60W - 80W (with boost)
• Display: 16-inch WQUXGA (3840 x 2400) IPS Anti-Glare Non-Touch
  • Brightness: 800 nits
  • Color Gamut: 100% DCI-P3, HDR 400
  • Features: Dolby Vision®, X-Rite Factory Color Calibration, Low Blue Light
• Memory (RAM): 64GB DDR5-5600MHz (2 x 32GB SODIMM)
  • Max support: Up to 96GB
• Storage: 1TB SSD M.2 2280 PCIe Gen4 Performance TLC Opal
  • Multiple M.2 slots, RAID 0/1 support
• Operating System: Windows 11 Pro 64
• Keyboard: Backlit, Black with Numeric Keypad - English (US), Spill-resistant
• Pointing Devices: TrackPoint, 115mm TrackPad with 3 buttons
• Webcam: 5MP RGB+IR with Dual Microphone, Privacy Shutter, Human Presence Detection
• Audio: Dolby Audio™, Dolby Voice®, Stereo speakers (2x 2W)
• Ports:
  • 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps, with PD 3.0, DP 2.1)
  • 1x USB-A (USB 5Gbps / USB 3.2 Gen 1, Always On)
  • 1x HDMI® 2.1 (up to 8K@60Hz)
  • 1x Ethernet (RJ45)
  • 1x SD Express 7.0 Card Reader
  • 1x Headphone/microphone combo jack (3.5mm)
• Wireless: Intel® Wi-Fi 6E AX211 (802.11ax 2x2) with vPro®, Bluetooth® 5.3
• WWAN: WWAN Ready (Antenna Only, No Card)
• Battery: Integrated 90Whr
• Power Adapter: 170W Slim Tip (3-pin)
• Dimensions (WxDxH): 365.00 x 262.00 x 24.66 mm (14.37 x 10.32 x 0.97 inches)
• Weight: Starting at 2.22 kg (4.90 lbs)
• Color: Black
• Security: Fingerprint Reader, Discrete TPM 2.0, ThinkShield
